RKC-ID1 Repack ICOM IC-ID-1 D-Star Digital Voice and Data 1200MHz w/FM Transceiver

 Icom Factory Reconditioned-Condition C   REPACK “C” CONDITION  Used to well used appearance, may have some minor scratches or show signs of use Original Gift box may not be included.  (Box may have major dents, writing, shipping labels, etc.) ALL MAJOR Accessories included: Base and Mobiles – Power cable and microphone HH’s – Antenna, Battery and Charger MAY NOT have the Owner’s Manual (Downloadable from IA website) 90-DAY Warranty from date of consumer purchase, must have proof of purchase       Discounts included in price: $25.00 instant rebate expires 6-31-15     128kbps digital data and 4.8kbps digital voice communication. No matter where you travel within the DSTAR network, you can access the web, e-mail, text messages and multimedia messages.   General Frequency coverage 1240-1300 MHz Type of emission FM, GMSK (Digital) Transmission speed Data Digital voice   128kbps 4.8kbps Codec AMBE (2.4kbps) No of memory channels: 100 regular 3 calls and 2 scan edges Frequency resolution 5, 6.25, 10, 12.5, 20, 25, 50, 100 kHz Operating temp. range: -10°C to +60°C; +14°F to +140°F Frequency stability ±2.5ppm (−10°C to +60°C) Power supply requirement 13.8V DC ±15% Current drain (at 13.8V DC;approx.) Rx AF max. Tx at 10W     Less than 1.5A Less than 7.0A Antenna impedance 50Ω (Type-N) Dimensions Main Unit  Remote Controller (Projections not included; W×H×D)141 × 40 × 165.8 mm; 59/16× 19/16 × 617/32 in150 × 50 × 49.5 mm; 529/32 × 131⁄32 × 115/16 in Weight (approx.) Main unit Remote controller   1.2kg; 2.6lb 220g; 7.7oz Transmitter Modulation system FM Digital   Variable reactance modulation Quadrature modulation Output power 10W/1W (Selectable) Max. frequency deviation: ±5.0 kHz (FM) Spurious emissions Less than -50dB Microphone connector: 8-pin modular jack (600Ω) Receiver Intermediate frequency FM, Digital voice Data   243.95 MHz/31.05 MHz/450 kHz (1st/2nd/3rd) 243.95 MHz/10.7 MHz (1st/2nd) Sensitivity FM Digital Voice Data (FM: at 12dB SINAD, Digital: at BER 1×10-2) Less than 0.18µV Less than 0.35µV Less than 1.58µV Squelch sensitivity Less than 0.18µV (FM, threshold) Selectivity (typical) FM   Digital voice   Data   More than 12 kHz/6dB Less than 30 kHz/60dB More than 6 kHz/6dB Less than 18 kHz/50dB More than 140 kHz/6dB Less than 520 kHz/40dB Spurious and image rejection More than 50dB Audio output power (at 13.8V DC) More than 2.0W at 10% distortion Ext. speaker connector 2-conductor 3.5 (d) mm (1/8")/8Ω Applicable U.S. Military Specifications Standard MIL 810 C MIL 810 D MIL 810 E MIL 810 F Method Proc Method Proc Method Proc Method Proc Low Pressure 500.1 I 500.2 I, II 500.3 I, II 500.4 I, II High Temp. 501.1 I 501.2 I, II 501.3 I, II 501.4 I, II Low Temp. 502.1 I 502.2 I, II 502.3 I, II 502.4 I, II Temp. Shock 503.1 I 503.2 I 503.3 I 503.4 I Solar Radiation 505.1 I 505.2 I 505.3 I 505.4 I Humidity 507.1 I, II 507.2 II, III 507.3 II, III 507.4 — Salt Fog 509.1 I 509.2 I 509.3 I 509.4 — Dust Blowing 510.1 I 510.2 I 510.3 I 510.4 I Vibration 514.2 VIII, X 514.3 I 514.4 I 514.5 I Shock 516.2 I, II, V 516.3 I, IV 516.4 I, IV 516.5 I, IV All stated specifications are subject to change without notice or obligation. Supplied Accessories Microphone Ethernet cable coupler USB extension cable (1.5 m; 4.9 ft) Ethernet cable (3 m; 9.8 ft) Remote controller (RC-24)* Mic extension cable (2.5 m; 8.2 ft)* External speaker, SP-22 DC power cable* Optional for some versions. System requirements for controller software Microsoft® Windows® 98/98SE/Me/2000/XP USB Port Ethernet port (for DD mode operation)     MTC is an authorized ICOM Dealer for factory reconditioned/refurbished (repacked) and warranted radio equipment and accessories.        ICOM reconditioned/refurbished equipment sold by MTC is covered by a full factory warranty for 90-Days from date of sale, and has been completely reconditioned tested and calibrated by ICOM factory service technicians. In addition to being tested and calibrated any available upgrades and/or firmware updates will be installed by ICOM factory service technicians.       FREE Shipping on ICOM Amateur radios and receivers to continental (lower 48)United States.       There are three Repack condition levels.  Below is a breakdown of these different classifications:       REPACK “A” CONDITION    “Like new”       Like New, No Scratches, Prime Equipment Gift box may have minor Dents, Writing, or Tape, looks like new ALL Accessories Included Owner’s Manual included 90-DAY Warranty from date of consumer purchase, must have proof of purchase       REPACK “B” CONDITION       Slightly used to used appearance, may have some minor scratches Original Gift box may not be included.  (Box may have dents, writing, shipping labels, etc.) ALL MAJOR Accessories included: Base and Mobiles – Power cable and microphone HH’s – Antenna, Battery and Charger MAY NOT have the Owner’s Manual (Downloadable from IA website) 90-DAY Warranty from date of consumer purchase, must have proof of purchase       REPACK “C” CONDITION        Used to well used appearance, may have some minor scratches or show signs of use Original Gift box may not be included.  (Box may have major dents, writing, shipping labels, etc.) ALL MAJOR Accessories included: Base and Mobiles – Power cable and microphone HH’s – Antenna, Battery and Charger MAY NOT have the Owner’s Manual (Downloadable from IA website) 90-DAY Warranty from date of consumer purchase, must have proof of purchase       The equipment available in this program will be from various replacement programs
