DR-135TMKIII 2M Mobile Free Shipping !
FREE SHIPPING! The Alinco DR-135TMKIII series features a full-featured 2 Meter 50 watt FM transceiver with an alphanumeric display (up to seven characters), 100 memory channels aircraft (AM) plus extended receive. Three power outputs (50/10/5 watts) are available. CTCSS encode and decode are standard. The receive range is 118-135.995 MHz (AM) and 136-173.995 MHz (FM). This radio is 5.55 x 1.61 x 6.06 inches 1.9 Lbs (141x41x154mm 0.86 kg). Enter the digital age with the optional EJ-40U. The DR-135 series each include the EMS-56 DTMF Hand Mic, mobile bracket, DC cord, alarm cable and mounting hardware. The DR-135T has a black case. The "P" versions include the EJ-41U Packet option factory installed. General Frequency range TX(T): 144-147.995MHz (FM) RX(T): 118-135.995 MHz (AM)136-173.995MHz (FM) TX&RX(E): 144-145.995MHz Operating mode 16K0F3E (FM)/8K50F3E (Narrow-FM)F1(9600bps)/F2(1200bps)/10F3 * 1/A3E (RX only DR135TMkII) Channel steps 5, 8.33, 10, 12.5, 15, 20, 25, 30, 50 KHz Memory channel 100 channels + 1 quick recall (CALL) Antenna impedance 50ohm unbalanced Frequency stability +/- 2.5ppm TCXO Power supply requirement 13.8V DC +/- 15% negative ground Current drain Approx. 11.0A TX HighApprox. 0.4A squelched Usable temperature range -10 - +60c (14 - 140F) Dimensions (w/o projection) 142(W) x 40(H) x 174(D) mm5.59"(W) x 1.57"(H) x 6.85"(D) Weight Approx. 1.0Kg (35.3oz) CTCSS tone encoder/decoder 39 tones Digital Coded Squelch encoder/decoder 104 codes Transmitter Output power Approx. 50W (HI)Approx. 20W (MID)Approx. 5W (LOW) Modulation system Variable reactance frequency modulation Spurious emission Less than -60 dB Maximum frequency deviation +/- 5 KHz (FM) / +/- 2.5 KHz (NFM) Receiver Receive system Double-conversion superheterodyne Sensitivity (-12dB SINAD) *2 Less than -16.0dBu Intermediate frequency 1st IF 21.7 MHz, 2nd IF 450 KHz Selectivity *2 -6dB: 12KHz or more-60dB: 28KHz or less (FM)-6dB: 6KHz or more-60dB: 16KHz or less (NFM) Audio output power More than 2W(8ohm 10%THD) Note: * 1 Optional units required* 2 Typical within the amateur radio band(s).
