Alinco DR-B185HT 85 Watt Two Meter VHF FM Mobile Transceiver DISCONTINUED
Features of DR-B185HT/HE Scanning functions including DCS/CTCSS/Priority/Group and timer/busy modes. Wide and Narrow FM modes 39 tone CTCSS/DCS/2-tone encode and decode HIGH/LOW power setting Offset direction and frequency variable Keypad lockout/Reverse function Alphanumeric tag/Display dimmer Automatic illumination brightness TIME-OUT-TIMERABCLO and AUTO POWER OFF TONE-BURST tones/AUTO-DIALER DTMF TX speed, pause and monitoring features S-METER squelch Multifunctional microphone with keypads (HT Only) Cable cloning and Free utility software (an optional PC cable required) Specifications Genaral DR-B185HT/HE Frequency coverageDR-B185HTDR-B185HE TX:144.000 - 147.995MHzRX:136.000 - 173.995MHzTX/RX:144.000 - 145.995MHz Operating mode 16k0F3E (FM/wide)/11k0F3E (FM/narrow) Antenna impedance 50ohm unbalanced Frequency stability +/- 2.5ppm Power supply requirement 13.8V DC +/- 15% (11.7 to 15.8V DC) Ground method Negative ground Current drain Receiver: 1.0A (max.) / Transmit: 20A Operating temperature -10digC to +60digC (+14digF to 140digF) Dimensions (w/o projection) 164 x 44 x 183.6 mm6.44 x 1.73 x 7.21 inches Weight 1.5Kgs / 3.31lbs Transmitter Power Output 85W High / 5W Low Modulation system FM: Reactance modulation Spurious emission Less than -50dB Unwanted sideband More than 50dB(1KHz) Maximum FM deviation +/- 2.5 KHz Receiver Receive system Double-conversion superheterodyne Sensitivity Wide: Less than 0.25uV, Narrow: Less than 0.25uV Intermediate frequency 1st IF 45.1MHz, 2nd IF 450 KHz Adjacent Channel Selectivity Wide: More than 70dB, Narrow: More than 60dB Spurious and image rejection ratio More than 65dB Audio output power More than 2.0W(8ohm 10%THD)
