Alinco DR-635T 2M/440 Mobile Dual Band Mobile
Call for a deal! The Alinco DR-635T is a new twin band mobile transceiver operating on the 2 meter and 70 cm bands. It has transmit coverage from 144 to 147.995 and 430-449.995 MHz. Receive coverage is 108 to 173.995 and 335 to 480 MHz. This includes the VHF air band in AM mode and the FM broadcast band 87.5 to 108 MHz in Wide FM mode. 200 alphanumeric memories are available. Power output on VHF is 50/20/5 watts and UHF is 35/20/5 watts. Dual band receiver with V/V, U/U, V/U and U/V capability. Yes, cross-band repeat is supported! The large, easy-to-read three color LCD shows status icons and alphanumeric tags. CTCSS & DCS encode/decode is included plus 4 different tone bursts. Other features include: auto power off, time out timer, tone burst, scan, channel lock-out, dimmer, VFO auto program, theft alarm function, narrow FM, power supply voltage display and remotable head. A fan on the rear panel insures cool operation during transmit. The front panel is remotable via the optional EDS-9 separation kit. The advanced 10F3 digital mode with speech compression technology is available via the optional EJ-47U board. The supplied EMS-57 Electret Condenser DTMF Hand Mic supports parameter setting and direct frequency entry. The radio also comes with DC cable, mobile mounting bracket with hardware, anti-theft (ACC on/off) function cable and anti-theft sticker. (The radio image above shows optional EDS9). Genaral Frequency range TX: USA VHF 144-147.995 MHzUHF 430-449.995 MHz TX: European VHF 144-145.995 MHzUHF 430-439.995 MHz RX: USA 108-173.995 MHz335-479.995 MHz87.5-107.995MHz RX: European 144-144.995 MHz430-439.995 MHz87.5-107.995MHz Modulation 16K0F3E(FM)/8K50F3E(Narrow FM)/F1E(digital voice)/F1D(9600bps)/F2D(1200bps)/A3E(RX only/AM) Channel Steps 5, 8.33, 10, 12.5, 15, 20, 25, 30, 50, 100 KHz Memory channel VHF 80ch / UHF 80ch / Free-programmable 40ch / 1ch VHF CALL / 1ch UHF CALL Antenna impedance 50 ohm unbalanced Frequency stability +/- 2.5 ppm Power Supply Requirement 13.8V DC +/- 15% Negative ground Current Drain Approx. 11A TX high / 700mA RX max. / 500mA RX squelched Usable temperature range -10c to +60c (14F to 140F) Dimensions 140mm(W) X 40mm(H) X 185mm(D)5.5 x 1.6 x 7.3 inches Weight Approx. 1kg or 35.3oz Transmitter Output High VHF 50W / UHF 35W, Mid 20W, Low 5W(approx.) Modulation System Variable Reactance Frequency Modulation Max.Frequency Deviation +/- 5KHz (FM) +/- 2.5KHz (NFM) Sprious emissions Less than -60dB Receiver Receive system Double Conversion Superheterodyne Intermediate Frequencies 1st 21.7MHz/450KHZ2nd 45.1MHz/455KHz Sensitivity(-12dB SINAD) Main band -14dBu(0.20uV) or betterSub band -12dBu(0.25uV) or better Squelch -18 dBu (0.1uV) or less Selectivity FM: -6dB: 12KHz or more, -60dB: 28KHz or less Audio Output 2W or more (8ohm 10% THD)
