Alinco DR-235T 220 Mobile DISCONTINUED
The Alinco DR-235 features a full-featured 220 MHz 25 watt FM transceiver with an alphanumeric display (up to seven characters) with 100 memory channels. Three power outputs (25/10/5 watts) are available. CTCSS encode and decode are standard. The receive range is 216.000 - 279.995 MHz (FM). Enter the digital age with the optional EJ-40U. This radio is 5.55 x 1.61 x 6.06 inches 1.9 Lbs (141x41x154mm 0.86 kg). The DR-235 series each include the EMS-56 DTMF Hand Mic (with metal plug), mobile bracket, DC cord, alarm cable and mounting hardware. The DR-235T has a black case (not shown). The DR-235TG pewter colored version (shown above) has been discontinued. Genaral Frequency range TX: 222.000 - 224.995 MHz RX: 216.000 - 279.995MHz Operating mode 16K0F3E (FM)/8K50F3E (Narrow-FM) Frequency resolution 5, 8.33, 10, 12.5, 15, 20, 25, 30, 50 KHz Memory channel 100 channels + 1 call channel Ant. impedance 50 ohm unbalanced Frequency stability +/- 2.5 ppm Microphone impedance 2K ohm Rated voltage 13.8 VDC +/- 15% (11.7-15.8V) Current Transmit: approx. 8.0AReceive: approx. 600mA (Max) 400mA (Squelched) Operating temperature -10Dig.C to +60Dig.C (+14Dig.F to +140Dig.F) Ground Negative ground Dimensions 142(W) x 40(H) x 174(D) mm5.58"(W) x 1.57"(H) x 6.83"(D) Weight Approx. 1.0Kg (35.3oz) Transmitter Power output 25W (HI)10W (MID)Approx. 5W (LOW) Modulation variable reactance Spurious emission -60 dB or less Maximum frequency deviation +/- 5 KHz / +/- 2.5 KHz (Narrow mode) Receiver Circuitry Double-conversion superheterodyne Sensitivity -12.0 dBu (0.25uV) or less (12dB SINAD) Intermediate frequency 1st IF 30.85MHz, 2nd IF 455 KHz Squelch sensitivity -16.0 dBu (0.1 uV) Selectivity (-6 dB) 12 KHz or more6 KHz or more (Narrow mode) Selectivity (-60 dB) 28 KHz or less14 KHz or less (Narrow mode) Audio output 2.0 W (8 ohm, 10% distortion) Features 100 Memories Front Panel GPS Input for APRS Ignition Key On/Off Feature Ten Autodial Memories Encode/Decode Theft Deterrent System Large Alphanumeric LCD Timer Out Timer Three Power Levels Optional TNC DTMF Microphone Dimmer
